Dimensions: 157(W) x 151(H) x 79(D)mm
|
SMB1 - SURFACE MOUNT BOX WITH BUILT IN HOOD FOR 1 MODULE
Surface Mounted Box housing 1 module
- Made from Anodised Aluminium
|
 |
Click to enlarge image
Dimensions: 157(W) x 241(H) x 79(D)mm
|
SMB2 - SURFACE MOUNT BOX WITH BUILT IN HOOD FOR 2 MODULES
Surface Mounted Box housing 2 modules vertically
- Made from Anodised Aluminium
|
|
Click to enlarge image
Dimensions: 157(W) x 331(H) x 79(D)mm
|
SMB3 - SURFACE MOUNT BOX WITH BUILT IN HOOD FOR 3 MODULES
Surface Mounted Box housing 3 modules
vertically
- Made from Anodised Aluminium
|
|
Dimensions: 157(W) x 421(H) x 79(D)mm
|
SMB4 - SURFACE MOUNT BOX WITH BUILT IN HOOD FOR
4 MODULES
Surface Mounted Box housing 4 modules vertically
- Made from Anodised Aluminium
|
|
Click to enlarge image
Dimensions: 286(W) x 241(H) x 79(D)mm
|
SMB4 (2x2) - SURFACE MOUNT BOX WITH BUILT IN HOOD FOR 4 MODULES
Surface Mounted Box housing 4 modules in a 2x2 configuration
- Made from Anodised Aluminium
|
|
Click to enlarge image
Dimensions: 286(W) x 331(H) x 79(D)mm
|
SMB6 - SURFACE MOUNT BOX WITH BUILT IN HOOD FOR 6 MODULES
Surface Mounted Box housing 6 modules in a 2x3 configuration
- Made from Anodised Aluminium
|
|
Click to enlarge image
|
SMBXX - SURFACE MOUNT BOXES - FOR LARGER APPLICATIONS
Larger SMBx boxes are available. Contact us for further details.
- For example: When building a 28 button application 2 x 4 module housing would be required
- Made from Anodised Aluminium
|
|
Click to enlarge image
Back box dimensions: 118(W) x 114(H) x 45 (D)mm
|
FMBB1 - FLUSH MOUNT BACK BOX FOR 1 MODULE
The FMBB1 is a back box that is fixed into the wall and should always be used in conjunction with the EWH1 when being installed outside.
- Houses 1 module
- Supplied with cosmetic surround and connectors for joining boxes
|
|
Click to enlarge image
Back box dimensions: 118(W) x 204(H) x 45 (D)mm
|
FMBB2 - FLUSH MOUNT BACK BOX FOR 2 MODULES
The FMBB2 is a back box that is fixed into the wall and should always be used in conjunction with the EWH2 when being installed outside.
- Houses 2 modules vertically
- Supplied with cosmetic surround and connectors for joining
boxes
|
|
Back box dimensions: 118(W) x 294(H) x 45 (D)mm
|
FMBB3 - FLUSH MOUNT BACK BOX FOR 3 MODULES
The FMBB3 is a back box that is fixed into the wall and should always be used in conjunction with the EWH3 when being installed outside.
- Houses 3 modules vertically
- Supplied with cosmetic surround and connectors for joining
boxes
|
|
Back box dimensions: 118(W) x 384(H) x 45 (D)mm
|
FMBB4 - ULYDOR FLUSH MOUNT BACK BOX FOR 4 MODULES
The FMBB4 is a back box that is fixed into the wall and should always be used in conjunction with the EWH4 when being installed outside.
- Houses 4 modules vertically
- Supplied with cosmetic surround and connectors for joining
boxes
|
|
Click to enlarge image
|
FMBBXX - FLUSH MOUNT BACK BOX - FOR LARGER APPLICATIONS
Larger FMBBx boxes are available. Contact us for further details.
- For example: When building a 28 button application 2 x 4 module housing would be required
|
|
Click to enlarge image
Dimensions: 151(W) x 149(H) x 49(D)mm
|
EWH1 - EXTERIOR WEATHER HOOD FOR 1 MODULE
The EWH1 should always be used in conjunction with FMBB1
|
|
Click to enlarge image
Dimensions: 151(W) x 241(H) x 49(D)mm
|
EWH2 - EXTERIOR WEATHER HOOD FOR 2 MODULES
The EWH2 should always be used in conjunction with FMBB2
|
|
Click to enlarge image
Dimensions: 151(W) x 331(H) x 49(D)mm
|
EWH3 - EXTERIOR WEATHER HOOD FOR 3 MODULES
The EWH3 should always be used in conjunction with FMBB3
|
|
Click to enlarge image
Dimensions: 151(W) x 421(H) x 49(D)mm
|
EWH4 - EXTERIOR WEATHER HOOD FOR 4 MODULES
The EWH4 should always be used in conjunction with FMBB4
|
